Curved Tooth Couplings

• RODX Drum Gear Coupling

  Intermediate Connecting Shaft

  RODX Drum Gear Coupling is an extended type of ROD series coupling with a floating shaft design in the middle, suitable for increasing transmission distance.

  View More
• RODP Drum Gear Coupling

  With Brake Discs

  The RODP Drum Gear Coupling is a type of ROD series coupling with a brake disc, suitable for transmission situations where braking needs to be used in conjunction with disc brakes.

  View More
• RODF Drum Gear Coupling

  Split Type, Brake Disc

  The RODF Drum Gear Coupling is a type of ROD series coupling with split brake discs, suitable for transmission situations where there is braking demand and the braking position changes when used in conjunction with disc brakes.

  View More
• RODW Drum Gear Coupling

  With Brake Wheel

  The RODW Drum Gear Coupling is a type of ROD series coupling with brake wheels, suitable for transmission situations where braking needs to be used in conjunction with wheel brakes.

  View More
• RODU Drum Gear Coupling

  With Brake Wheel

  The RODU Drum Gear Coupling is another type of ROD series coupling with brake wheels, suitable for transmission situations where braking needs to be used in conjunction with wheel brakes and applied to one end of the axle, achieving smoother and more reliable braking performance.

  View More
• RODV Drum Gear Coupling

  Vertical Installation

  The RODV Drum Gear Coupling is a vertical installation type of the ROD series coupling, suitable for transmission situations that require vertical transmission torque.

  View More
• RODM Drum Gear Coupling

  Torsion Protection

  The RODM Drum Gear Coupling is a torque setting form of the ROD series coupling. By adjusting relevant components, the maximum transmission torque can be easily set within a certain range. Suitable for shafting transmission situations that require safe torque operation to protect important machine components from excessive damage.

  View More
• GICL Drum Gear Coupling

  Wide

  GICL Drum Gear Coupling has larger inner teeth width, which can transfer torque while compensating for larger axial displacement.

  View More
• GICLZ Drum Gear Coupling

  Connected to Intermediate Shaft

  Half of the GICLZ Drum Gear Coupling adopts a non-toothed semi-coupling sleeve structure, which is usually connected in pairs or used in occasions with small angular displacement.

  View More
• GIICL Drum Gear Coupling

  Narrow

  GIICL Drum Gear Coupling has small inner teeth width, which can transfer torque while compensating for small axial displacement. Also, its structure is compact and the moment of inertia is low.

  View More
• GIICLZ Drum Gear Coupling

  Connected to Intermediate Shaft

  Half of the GIICLZ Drum Gear Coupling adopts a non-toothed semi-coupling sleeve structure, which is usually connected in pairs or used in occasions with small angular displacement. Also, its structure is compact and the moment of inertia is low.

  View More
• GCLD Drum Gear Coupling

  Motor Shaft Extension

  GCLD Drum Gear Coupling is generally used for direct connection with the motor, so it generally has a higher speed and compact structure.

  View More
• NGCL Drum Gear Coupling

  With Brake Wheel

  NGCL Drum Gear Coupling is designed with a brake wheel, suitable for situations where braking is required.

  View More
• NGCLZ Drum Gear Coupling

  With Brake Wheel

  NGCLZ Drum Gear Coupling is designed with a brake wheel, suitable for situations where braking is required. Half of its structure adopts a semi-coupling sleeve design, with smaller angular displacement compensation but more stable braking.

  View More
• WG Drum Gear Coupling

  Basic

  The overall characteristics of WG Drum Gear Coupling are similar to those of other drum gear couplings, but with a larger modulus design, which can generally transmit greater torque.

  View More
• WGZ Drum Gear Coupling

  With Brake Wheel

  WGZ Drum Gear Coupling is designed with a brake wheel, suitable for shoe type braking.

  View More
• WGP Drum Gear Coupling

  With Brake Discs

  WGP Drum Gear Coupling is designed with a brake disc, suitable for disc type braking.

  View More
• WGT Drum Gear Coupling

  Intermediate Connecting Pipe

  WGT Drum Gear Coupling is designed with indirect tube, suitable for long distance torque transfer.

  View More
• WGC Drum Gear Coupling

  Vertical Installation

  WGC Drum Gear Coupling is specially designed for situations where vertical transmission is required, suitable for some vertical transmission systems.

  View More
• WGJ Drum Gear Coupling

  Connected to Intermediate Shaft

  WGJ Drum Gear Coupling is designed with intermediate shaft, suitable for long distance torque transmission, and some are equipped with axial buffers.

  View More

« Curved Tooth Couplings » Post Date: 2023/12/13
